Outdoor UHF RFID Tag – UV-Resistant & IP68
Reliable RFID Identification on Metal and Non-Metal Surfaces
Our outdoor UHF RFID tag deliver reliable performance on both metal (conductive) and non-metal (dielectric) surfaces, offering a flexible solution for industrial asset identification and tracking.
With a durable, UV-resistant ASA housing and IP68 protection, the tags suit indoor and outdoor applications exposed to moisture, dust, and sunlight.
The specially designed antenna provides 360° orientation-independent reading, maintaining consistent read range regardless of the tag’s rotational position around its axis. This minimizes orientation-related reading limitations and simplifies installation.
Available with Impinj or NXP RFID chips, the tags offer flexible configurations to meet different application requirements.
Key Features:
- All-Surface Compatibility – Designed for use on metal and non-metal surfaces.
- UV-Resistant ASA Housing – Weather-resistant material suitable for outdoor applications.
- IP68 Protection – Dust-tight and protected against water immersion under specified conditions.
- 360° Orientation-Independent Reading – Consistent read range during rotation around the tag axis.
- Impinj & NXP Chip Options – Flexible chip and memory configurations.
- Indoor & Outdoor Applications – Suitable for industrial asset tracking and identification.
Typical Applications
- Industrial asset tracking and identification
- Machinery and equipment identification
- Outdoor asset management
- Warehouse and inventory management
- Industrial logistics and material tracking
⊕ Click to expand
| Frequency: | 865 – 928 MHz |
| Type: | EPC Class 1 Gen 2 |
| Chip: | NXP UCode9, Impinj Monza 4QT, M-700 |
| Reading Range: | Up to 8 m 2W/ ERP, depend on application |
| Operating Temperature: | -25°C + 85°C |
| Dimension (L x W x H): | 50 mm x 35 mm x 20 mm |
| Housing: | ASA, UV-resistant |
| IP Classification: | IP 68 |
| Applications: | Logistics & Warehouse Management, etc |
| H86-M4QT-3D-5050 | Outdoor UHF RFID Tag UV-resistant, Impinj Monza 4QT |
| H86-U9-3D-5050 | Outdoor UHF RFID Tag UV-resistant, Impinj NXP UCode9 |
